Zanussi 504274 Warewashing Hood Type Dishwasher, Manual with Continuous Water Softener & Advanced Filtering System

  • 45/84/150 seconds cycles (High productivity mode); 57/84/150 seconds cycles (NSF/ANSI 3 mode).

  • Maximum capacity per hour of 80 racks or 1.440 dishes (High productivity mode) easy to switch to 63 racks or 1.134 dishes (NSF/ANSI 3 mode) by pressing a button.

  • NSF/ANSI 3 and DIN 10512 compliant.

  • Green light of Guaranteed Rinse System (ACTIVE) confirms that items have been rinsed properly.

  • Advanced Filtering System provides cleaner wash water and higher active detergent thus ensuring better washing performances and lower running costs.

  • CLEAR BLUE advanced filtering system provides cleaner wash water and higher active detergent thus ensuring better washing performances and lower running costs.

  • Continuous Water Softener (CWS) to ensure that 100% of the water entering the dishwasher is softened thus providing spot-free results.

  • Built-in atmospheric boiler sized to raise incoming water to a minimum of minimum 84 °C for sanitizing rinse. No external booster is required. Constant temperature of 84 °C throughout the rinsing cycle regardless of the network's water pressure.

  • Automatic regeneration of CWS during the wash cycle, based on water consumption, guarantees non-stop dish washing.

  • Unique temperature interlock guarantees required temperatures in both the wash and final rinse in case of emergency cold water feeding.

  • Incorporated Soft Start feature to offer additional protection to more delicate items.

  • Slanted wash arms and sloped ceiling to avoid detergent-filled wash water dropping on clean dishes after the rinsing phase, thus guaranteeing ideal washing results.

  • Cycle may be interrupted at any time by lifting the hood.

  • Automatic self-cleaning cycle and self-draining vertical wash pump and boiler to avoid bacteria proliferation.

  • State-of-the-art electronic controls with built-in programming, self-diagnostics for serviceability and automatic interior self-cleaning cycle.

  • Built-in rinse aid and detergent dispenser with automatic initial and continuous cycle loading for perfect result while minimizing service and maintenance needs.

  • Boiler power setting from control panel to facilitate technician's operation when reducing total installed power, thus avoiding the need of machine opening.

  • Three phase electrical connection, convertible to single phase on-site.

  • IP25 protection against water jets, solid objects and small animals (larger than 6 mm).

  • Heavy duty Stainless steel construction. Internal cavity as well as exterior panels are in 304 series Stainless steel.

  • Pressed tank in front position to facilitate cleaning.

  • Double skin insulated hood.

  • Specially designed Stainless steel wash/rinse arms and nozzles provide superior cleaning action.

  • Revolving interchangeable Stainless steel wash/rinse arms above and below the rack, screw out for simple clean up.

  • Pre-arranged for on-site HACCP implementation and Energy Management device.

  • Element protection from dry fire and low water.

  • Unit to include drain, detergent and rinse aid dispenser pumps

Description / Zanussi 504274 Warewashing Hood Type Dishwasher, Manual with Continuous Water Softener & Advanced Filtering System

The Zanussi 504274 Warewashing Hood Type Dishwasher, Manual with Continuous Water Softener & Advanced Filtering System comes from one of the outstanding brands in foodservice and laundry equipment. Famed for their high quality and precision engineering, the Zanussi Professional brands are renowned for their range of equipment.

Electric
  • Supply voltage: 400 V/3N ph/50 Hz
  • Convertible to: 230V 1N~; 230V 3~
  • Default Installed Power: 9.9 kW
  • Reducible Installed Power:* 6.9 kW
  • Boiler Heating Elements Power: 9 kW
  • Boiler Reducible To:* 6 kW
  • Tank heating elements: 3 kW
Water:
  • Drain line size: 20.5mm
  • Inlet water supply pressure: 0.5-7 bar
  • Boiler Capacity (lt): 12
  • Tank Capacity (lt): 24
Air Emission:
  • Latent heat: 500 W
  • Sensible heat: 2000 W
Sustainability
  • Water supply temperature*: 10-65 °C
  • Water consumption per cycle (lt): 2
  • Noise level: <63 dBA
Key Information:
  • N° of cycles: 3
  • Duration cycle:* 45/84/150 sec.
  • Duration cycle - NSF/ANSI 3 compliant: 57/84/150 sec.
  • Racks per hour:* 80
  • Racks per hour - NSF/ANSI 3 compliant: 63
  • Dishes per hour:* 1440
  • Dishes per hour - NSF/ANSI 3 compliant: 1134
  • Wash temperature: 55-65 °C
  • Wash temperature - NSF/ANSI 3 compliant: 75 °C
  • Rinse temperature: 84 °C
  • Net weight: 117 kg
  • Shipping weight: 129 kg
  • Shipping volume: 1.23 m³
  • Packaging size

    (WxDxH): 752x755x1567 mm

  • * According to market standard, the productivity is declared at an inlet water supply temperature of 50°C . If the water is supplied at 65°C, the power can be reduced by 3 kW without any loss in productivity.
  • ** When connected to cold water, the cycle time will be prolonged accordingly. The machine will have productivity per hour of 48 racks at 10°C supply temperature or 55 racks at 20°C supply temperature.
Brochures
(2,02 MB)
CAD Drawings
(113,19 KB)
Data Sheet
BIM/Revit
(996 KB)

The Zanussi 504274 Warewashing Hood Type Dishwasher, Manual with Continuous Water Softener & Advanced Filtering System is certified for use in most countries and can be ordered at different specifications to suit your commercial kitchen. We export catering equipment to all countries in the world so customising your Zanussi Professional appliance is not a problem. This item may also be suitable for use in galley kitchens.

For further information please download the brochures using the link above or please call us on 0044 (0)117 405 7580.
