Zanussi 392167 Modular Cooking Range Line EVO900 4-Electric Hot Plate Range on Electric Oven
Top configuration allows installation on ambient base only (not possible to install on refrigerated nor freezer base).
Unit to be mounted on stainless steel feet with height adjustment up to 50 mm. Unit can be easily mounted on cantilever systems.
The four 4kW electric cast-iron hot plates are hermetically sealed to the one piece top and are featured with safety thermostat.
Base compartment consists of an electric standard oven with 40 mm thick oven door for heat insulation, positioned beneath the base plate.
Oven chamber with 3 levels of runners to accomodate 2/1 GN shelves (2 steam pans).
-
Ribbed cast iron oven base plate.
-
Oven to feature separate thermostats for top and bottom elements. Thermostat temperature adjustable from 110°C to 285°C.
-
The special design of the control knob system guarantees against water infiltration.
IPX5 water protection.
-
Unit is 900mm deep to give a larger working surface area.
-
All exterior panels in Stainless Steel with Scotch Brite finishing.
-
AISI 304 stainless steel worktop, 2mm thick.
Model has right-angled side edges to allow flush fitting joints between units, eliminating gaps and possible dirt traps.
Description / Zanussi 392167 Modular Cooking Range Line EVO900 4-Electric Hot Plate Range on Electric Oven
The Zanussi 392167 Modular Cooking Range Line EVO900 4-Electric Hot Plate Range on Electric Oven comes from one of the outstanding brands in foodservice and laundry equipment. Famed for their high quality and precision engineering, the Zanussi Professional brands are renowned for their range of equipment.
Electric
- Supply voltage: 230 V/3 ph/50/60 Hz
- Electrical power max.: 22 kW
- Total Watts: 22 kW
- Predisposed for:
Key Information:
- Front Plates Power: 4 - 4 kW
- Back Plates Power: 4 - 4 kW
- Front Plates dimensions: 300x300 300x300
- Back Plates dimensions: 300x300 300x300
- Oven Heat Input: 6 kW
- Oven working Temperature: 110 °C MIN; 285 °C MAX
- Oven Cavity Dimensions (width): 575 mm
- Oven Cavity Dimensions (height): 300 mm
- Oven Cavity Dimensions (depth): 700 mm
- External dimensions, Width: 800 mm
- External dimensions, Depth: 900 mm
- External dimensions, Height: 850 mm
- Net weight: 145 kg
- Shipping weight: 139 kg
- Shipping height: 1120 mm
- Shipping width: 1020 mm
- Shipping depth: 860 mm
- Shipping volume: 0.98 m³
- If appliance is set up or next to or against temperature sensitive furniture or similar, a safety gap of approximately 150 mm should be maintained or some form of heat insulation fitted.
- Certification group: N9CE1
Brochures
Range overviews
CAD Drawings
Data Sheet
BIM/Revit
The Zanussi 392167 Modular Cooking Range Line EVO900 4-Electric Hot Plate Range on Electric Oven is certified for use in most countries and can be ordered at different specifications to suit your commercial kitchen. We export catering equipment to all countries in the world so customising your Zanussi Professional appliance is not a problem. This item may also be suitable for use in galley kitchens.
For further information please download the brochures using the link above or please call us on 0044 (0)117 405 7580.
