Zanussi 392165 Modular Cooking Range Line EVO900 2-Hot Plates Electric Boiling Top
Top configuration allows installation on ambient base only (not possible to install on refrigerated nor freezer base).
Suitable for countertop installation.
Unit to be mounted on open base cupboards, bridging supports or cantilever systems.
The two 4kW cast-iron plates are hermtically sealed to the one-piece top. Hot plates with a power of 4kW for each plate.
The special design of the control knob system guarantees against water infiltration.
-
IPX5 water protection.
-
Unit is 900mm deep to give a larger working surface area.
-
All exterior panels in Stainless Steel with Scotch Brite finishing.
AISI 304 stainless steel worktop, 2mm thick.
-
Model has right-angled side edges to allow flush fitting joints between units, eliminating gaps and possible dirt traps.
Description / Zanussi 392165 Modular Cooking Range Line EVO900 2-Hot Plates Electric Boiling Top
The Zanussi 392165 Modular Cooking Range Line EVO900 2-Hot Plates Electric Boiling Top comes from one of the outstanding brands in foodservice and laundry equipment. Famed for their high quality and precision engineering, the Zanussi Professional brands are renowned for their range of equipment.
Electric
- Supply voltage: 230 V/3 ph/50/60 Hz
- Total Watts: 8 kW
- Predisposed for:
Key Information:
- Front Plates Power: 4 - 0 kW
- Back Plates Power: 4 - kW
- Front Plates dimensions: 300x300
- Back Plates dimensions: 300x300
- Net weight: 35 kg
- Shipping weight: 45 kg
- Shipping height: 540 mm
- Shipping width: 460 mm
- Shipping depth: 1020 mm
- Shipping volume: 0.25 m³
- Certification group: N9CE1
Brochures
Range overviews
CAD Drawings
Data Sheet
BIM/Revit
The Zanussi 392165 Modular Cooking Range Line EVO900 2-Hot Plates Electric Boiling Top is certified for use in most countries and can be ordered at different specifications to suit your commercial kitchen. We export catering equipment to all countries in the world so customising your Zanussi Professional appliance is not a problem. This item may also be suitable for use in galley kitchens.
For further information please download the brochures using the link above or please call us on 0044 (0)117 405 7580.
