The Electrolux Undercounter WSC, double skin, drain pump & rinse aid dispenser, 720d/h-60Hz PNC 502705 comes from one of the outstanding brands in foodservice and laundry equipment. Famed for their high quality and precision engineering, the Electrolux Professional brand is renowned for its range of equipment.

Specifications

Electric

• Supply voltage: 400 V/3N ph/60 Hz
• Convertible to: 230V 3~; 230V 1N~
• Default Installed Power: 5.35 kW
• Boiler heating elements: 4,5 kW
• Tank heating elements: 2 kW
• Wash pump size: 0.736 kW

Key Information:

• Baskets per hour*: 40
• Dishes per hour: 720
• Working cycles time (sec.): 90/120/240
• Wash temperature: 55-65C
• Cell dimensions - width: 500 mm
• Cell dimensions - depth: 500 mm
• Cell dimensions - height: 335 mm
• Rinse temperature: 84 C
• External dimensions, Width: 600 mm
• External dimensions, Height: 820 mm
• External dimensions, Depth: 615 mm
• Packaging size

  (WxDxH): 600x612x850 mm
• Noise level: 61 dBA

Water:

• Pressure, bar min/max: 0.5-7 bar
• Water supply temperature*: 50 C
• Drain line size: 20.5mm
• Inlet Water supply pressure: 7 - 102 psi (0.5 - 7 bar)
• Washing tank capacity (lt): 23
• Water consumption per cycle (lt): 2.5
• Boiler Capacity (lt): 12

The Electrolux Undercounter WSC, double skin, drain pump & rinse aid dispenser, 720d/h-60Hz PNC 502705 is certified for use in most countries and can be ordered at different specifications to suit your commercial kitchen. We export catering equipment to all countries in the world so customising your Electrolux appliance is not a problem. This item may also be suitable for use in galley kitchens.

For further information please download the brochure using the link above or please call us on 0044 (0)117 405 7580.
