Electrolux Large Pot & Pan Washer with Drain Pump & Detergent Dispenser PNC 506064

Electrolux

£17,408.40 £14,507.00

In stock

SKU

506064

Main Features

Industrial cleaning machine to wash and sanitize protective personal equipments in steel, composite, rubber, fabric, plastic etc. from grease, residues of combustion gases, toxins etc. in just few minutes to save time and minimize contamination
Door divided in two parts with 180 frontal opening for a better and easier load.
Fault auto-diagnosis system. Self-cleaning cycle. Drain pump and detergent dispenser included.
Pre-arrangements for connection to an automatic detergent dispenser.
IPX5 water protection.
Low noise level.
Simple service from the front.
304 AISI stainless steel front and side panels, wash tank, tank filter and wash and rinse arms.
Equipped with side washing arms in addition to upper and lower wash arms.

Electric Pot&Pan Washer with electronic control, drain pump, detergent dispenser

Details

The Electrolux Large Pot & Pan Washer with Drain Pump & Detergent Dispenser PNC 506064 comes from one of the outstanding brands in foodservice and laundry equipment. Famed for their high quality and precision engineering, the Electrolux Professional brand is renowned for its range of equipment.

Specifications

Electric

Supply voltage: 400 V/3N ph/50 Hz
Default Installed Power: 17 kW
Electrical power max.: 26 kW
Wash pump power: 5 kW

Key Information:

Washing cycle temperature: 55-65 C
Hot rinse cycle temperature: 60 C
N of working cycles: 4 (180/360/540/inf)
Cell dimensions - width: 1340 mm
Cell dimensions - depth: 710 mm
Cell dimensions - height: 570 mm
External dimensions, Width: 1552 mm
External dimensions, Height: 1791 mm
External dimensions, Depth: 900 mm
Net weight: 300 kg
Shipping weight: 340 kg
Shipping height: 2030 mm
Shipping width: 1800 mm
Shipping depth: 1100 mm
Shipping volume: 4.02 m

Water:

Pressure, bar min/max: 0.5-7 bar
Water supply temperature*: 50 C
Washing tank capacity (lt): 150
Boiler Capacity (lt): 18
Washing cycle electrical elements: 10,5 kW
Hot rinse cycle duration (sec.): 20
Rinsing water consumption (per cycle): 12 lt

The Electrolux Large Pot & Pan Washer with Drain Pump & Detergent Dispenser PNC 506064 is certified for use in most countries and can be ordered at different specifications to suit your commercial kitchen. We export catering equipment to all countries in the world so customising your Electrolux appliance is not a problem. This item may also be suitable for use in galley kitchens.

For further information please download the brochure using the link above or please call us on 0044 (0)117 325 0588.
