Electrolux green&clean Hood Type dishwasher, 80 racks/hour PNC 505100

Main Features

• NSF/ANSI 3 and DIN 10512 compliant.

• Maximum capacity per hour of 80 racks or 1.440 dishes (High productivity mode) easy to switch to 63 racks or 1.134 dishes (NSF/ANSI 3 mode) by pressing a button.

• 45/84/150 seconds cycles (High productivity mode); 57/84/150 seconds cycles (NSF/ANSI 3 mode).

• The machine can be connected to cold water.

• Requires only 2 liters of water per washing cycle thus ensuring low energy, water, detergent and rinse aid consumption.

• Built-in atmospheric boiler sized to raise incoming water to a minimum of minimum 84 C for sanitizing rinse. No external booster is required. Constant temperature of 84 C throughout the rinsing cycle regardless of the network's water pressure.

• Unique temperature interlock guarantees required temperatures in both the wash and final rinse.

• Incorporated Soft Start feature to offer additional protection to more delicate items.

• Slanted wash arms to avoid detergent-filled wash water dropping on clean dishes after the rinsing phase, thus guaranteeing ideal washing results.

• Cycle may be interrupted at any time by lifting the hood.

• Automatic self-cleaning cycle and self-draining vertical wash pump and boiler to avoid bacteria proliferation.

• State-of-the-art electronic controls with built-in programming, self-diagnostics for serviceability and automatic interior self-cleaning cycle.

• Built-in rinse aid dispenser with automatic initial and continuous cycle loading for perfect result while minimizing service and maintenance needs.

• Boiler power setting from control panel to facilitate technician's operation when reducing total installed power, thus avoiding the need of machine opening.

• Three phase electrical connection, convertible to single phase on-site.

• IP25 protection against water jets, solid objects and small animals (larger than 6 mm).

• Heavy duty Stainless steel construction. Internal cavity as well as exterior panels are in 304 series Stainless steel.

• Pressed tank in front position to facilitate cleaning.

• Single skin hood supported by 3 springs to ensure smooth movement and guarantee operator safety.

• Specially designed Stainless steel wash/rinse arms and nozzles provide superior cleaning action.

• Revolving interchangeable Stainless steel wash/rinse arms above and below the rack, screw out for simple clean up.

• Pre-arranged for on-site HACCP implementation and Energy Management device.

• Element protection from dry fire and low water.

Hood Type Dishwasher, with single skin manual hood, atmospheric boiler, built-in rinse aid dispenser, 80r/h
