Electrolux Drop-in remote refrigerated well with refrigerated display, squared, medium service - 4 hours - 5GN PNC 341117

Main Features

• Bottom part of well is removable for an easier access to the evaporator.

• Preadjusted connection to remote cooling unit (not included).

• Suitable for GN 1/1 containers with a maximum height of 150 mm.

• CB and CE certifed by a third party notified body.

• Designed to be positioned in flush installation providing improved cleanability and suitable for modern design installations.

• Precise temperature control and setting at 0,1C .

• As standard the product comes with digitally controlled thermostat which is in line of HACCP norms and provides visual alarm as a warning of the increasing or decreasing temperatures.

• Food introduced at the correct temperature maintains its core temperature according to Afnor Standards.

• Automatic defrosting guarantees evaporators clearance and efficient well cooling.

• Available drop-in dimensions: 2, 3, 4, 5 GN.

• Well equipped with adjustable bottom that can be set to 5 positions for each GN 1/1 section, independently one from the other to display different items with different heights.

• Front grids and well bottom panels can be removed without the need of any tool for fast and effective cleaning.

• Well can be cleaned with a hose (after removing easily the fans).

• Designed to serve: plates on the shelves and food in GN containers or food on plates/packages or bottles and cans thanks to adjustable bottom well.

• The temperature uniformity is guaranteed by powerfull fans and high surface evaporator and air conveyours placed at the back of the shelves.

• The display is illuminated by inside LED light under each glass shelf that emphasizes the cold food colors.

• Includes three adjustable 8 mm thick tempered glass shelves that can be installed horizontally or inclined to better display dishes.

• Short sides, back sliding doors and the top are in double glazed low emission glass (18 mm thick) to improve insulation avoiding formation of the condensation and reducing energy consumption.

• Equipped with self lifting curtain to reduce energy dispersion when the unit is not in use.

• Equipped with two sliding doors on the operator side with hold function allowing easy fill-up auto close function in order to ensure the doors always remain closed when not in use.

• The air circulation has been studied in order to guarantee temperature uniformity in every and each section of the well and shelves.

• Designed for extra increased visibility on the shelves for charming food display.

• Closed on customer side or flaps on customer side options are available.

• Built-in cooling unit version is available.

• Well bottom is inclined to facilitate water drainage.

• Environmentally friendly: R452a as refrigerant gas.

• Well in 304 AISI stainless steel with rounded corners to facilitate cleaning operations. The well is also equipped with a drain hole.

• Electronic control with temperature display.

• High-density expanded polyurethane foam with cyclopenthane guarantees excellent well insulation to reduce energy dispersion.

• IPx2 water protection.

Drop-in remote refrigerated well with refrigerated display, squared, medium service - 4 hours - (5 GN container capacity)
