Electrolux 691388 1-door prostore Freezer 470lt, -22-15°C, AISI 304 - R290 (Marine) 50Hz

Prostore 500 1 Door Digital Freezer, 470lt (-15/-22°C) R290 (Marine) 50Hz

Product Features

Adjustable temperature range from -15°C to -22°C.

Performance guaranteed at ambient temperatures of +40°C (Climatic class 5).

Large digital white-digit display with cabinet temperature display and setting and turbo frost cycle (to rapidly cool warm loads).

Optimized airflow within the chamber guarantees uniformity of temperature on all grids.

Connectivity ready for real time access to connected appliances from remote and data monitoring (requires optional accessory).

Fully compliant HACCP digital control: when temperature exceeds critical limits, acoustic and visual alarms are activated.

Greater storage space: internal structure with numerous charging positions available to host grids, ensuring higher net capacity.

Hidden evaporator thus guaranteeing higher storage capacity and less corrosion problems.

Large storage area suitable to contain 520x442 mm grids or shelves to improve net capacity.

AISI 304 runners with grids stopper for Marine installations.

Self closing and on site reversible left/right doors.

Tropicalized unit.

Model requires only 1 phase 230V/50Hz supply and can be plugged straight into an existing power socket.

Low noise level.

Complies with main international certification bodies and is CE marked.

Stainless steel AISI 304 external panels (galvanized external back).

Pressed stainless steel door handle without joints gathering dust and dirt.

Inner cell with rounded corners, bottom pressed in only one piece.

Easy access to the main components for maintenance.

Internal components removable without the use of tools to facilitate cleaning operations.

Lockable door.

Mounted on Marine feet.

Kit of 4 feet H=67mm available as optional in case of ceiling up to 2100mm.

Developed and produced in ISO 9001 and ISO 14001 certified factory.

Automatic heated door frame.

Description / Electrolux 691388 1-door prostore Freezer 470lt, -22-15°C, AISI 304 - R290 (Marine) 50Hz

The Electrolux 691388 1-door prostore Freezer 470lt, -22-15°C, AISI 304 - R290 (Marine) 50Hz comes from one of the outstanding brands in foodservice and laundry equipment. Famed for their high quality and precision engineering, the Electrolux Professional brand is renowned for its range of equipment.

Specifications

Electric

Supply voltage: 220-230 V/1 ph/50 Hz

Electrical power max.: 0.49 kW
Key Information

Gross capacity: 470 lt

Net Volume: 317 lt

Door hinges: Right Side

External dimensions, Width: 600 mm

External dimensions, Depth: 700 mm

External dimensions, Depth with Doors Open: 1226 mm

External dimensions, Height: 2040 mm

Number and type of doors: 1 Full

Internal Dimensions, Width: 472 mm

Internal Dimensions, Depth: 582 mm

Internal Dimensions, Height: 1474 mm

Height adjustment: 15/40 mm

Number and type of grids (included): 4 - 520x442

Type of external material: 304 AISI

Type of internal material: 304 AISI

Number of positions & pitch: 44; 22 mm
Refrigeration Data

Control type: Digital

Compressor power: 3/4 hp

Refrigeration power at evaporation temperature: -30 °C

Operating temperature min.: -22 °C

Operating temperature max.: -15 °C

Operating mode: Ventilated

Cooling unit: Built-In

Defrost type: Electric
Sustainability

Refrigerant type: R290

Refrigeration power: 568 W

Refrigerant weight: 125 g
ISO Certificates

ISO Standards: ISO 9001; ISO 14001; ISO 45001; ISO 50001

Documents

The Electrolux 691388 1-door prostore Freezer 470lt, -22-15°C, AISI 304 - R290 (Marine) 50Hz is certified for use in most countries and can be ordered at different specifications to suit your commercial kitchen. We export catering equipment to all countries in the world so customising your Electrolux appliance is not a problem. This item may also be suitable for use in galley kitchens.

For further information please download the brochure using the link above or please call us on 0044 (0)117 405 7580.
