• Counter-balanced lid with insulated stainless steel handle specially shaped to prevent condensation dripping outside the well. The tension on the counter-balancing chromed bronze hinge of the lid can be adjusted to ensure an optimum balance.
• Steam heating at a nominal pressure of 0.45 bar.
• Manometer to control the pressure inside the jacket.
• Safety valve set at 0.5 bar for the discharging of steam when the pressure in the jacket exceeds this limit.
• Depressurising valve to allow the escape of air from the jacket.
• Easy installation and maintenance thanks to compartment with connectors and controls placed on side.
• Complies with main international certification bodies and is CE marked.
• Stainless steel filter in the discharge hole of the well.
• Chromed bronze with movable spout mixer tap for hot and cold water.
• 2" diameter discharge tap for rapid emptying of the well.
• 316 AISI stainless steel bottom (ranging from 20/10 to 35/10 in thickness depending on the pan capacity) and is anti-corrosion treated. Grain finish less than 0.6 micron.
• 304 AISI stainless steel well jacket lid and external panelling (ranging from 20/10 to 25/10 in thickness depending on the pan capacity); the external panelling is dismountable to allow inspection of internal workings.
• Load bearing structure consists of a robust support in 304 AISI stainless steel mounted on stainless steel adjustable feet. Visible areas have a satin finish guaranteeing ease of cleaning.
